Product Details:
|
| Product Name: | Laminated PVC Wall Panels With Wooden Pattern | Material: | PVC |
|---|---|---|---|
| Size: | 250*8mm, Other Sizes Are Available | Length: | From 2.7m To 6m, Customized |
| Application: | Living Room, Office | Feature: | Wterproof, Tough, Decorative, Mothproof |
| High Light: | 3d wall panels,waterproof wall panels |
||
Quick Detail:
• Type: PVC wall panel
• Function: Fireproof, heat insulation, mould-proof, sound-absorbing, waterproof
• Feature: Artistic ceilings, honeycomb ceilings, integrated cceilings, perforated ceilings
• Ceiling Tile Shape: Strip
• Material: PVC Resin, calcium carbonate
• PVC content: 60%, 73%, 77%, 87%
• Weight: 1.5-4 kg/sqm
• Surface Process: Printing, Hot stamping, Lamination
• Quality Guarantee: 25 years
Applications:
In recent years PVC has become an advantageous alternative than traditional materials for decoration
of interior spaces in the various places such as residences, hotels, restaurants, industrial units, individual offices, bathrooms, kitchens, laundries.
Specifications:
| Product name | PVC Panel |
| Main material |
PVC (60%, 73%, 77%, 87% or as your request), calcium carbonate and other chemicals |
| Usual specification |
Length: customized size, such as 2.95m, 3m, 3.8m, 5.6m, 5.8m, 5.95m Width: 5cm to 40cm or customized Thickness: 5mm to 10mm or customized |
| Surface treatment |
Oil print, hot stamping foil, thermal transfer print, laminated and as to your pattern and color |
| Surface effect | Bright/glossy, high glossy, matt, gleam, roller coating |
| Production quality |
Light of weight, powerful strength, high intensity, heat insulation, flame resistant, corrode resistant, age resistant, no aspiration, easy cleaning, easy installing |
| Producing scale | With more than 60 PVC production lines and 100 kinds of moulds |
| Certificate | ISO9001:2000, Soncap, CE |
| Application |
Hotels, commercial buildings, hospital, schools, home kitchen, bathroom, indoor decoration and so on |
| Sample | Free with International Express Delivery |
Competitive Advantage:
We are professional in PVC extrusion products for more than 10 years. With advanced production lines
from Germany and Italy, we have a total annual capacity of over 5 million square meters PVC wall and
ceiling panels, over 6,000MT plastic-wood products, and over 2,000MT other PVC products. Our company has strong technology capability. We have more than 20 engineers and technicians who are specializing in developing new products. All kinds of types and design colors we have developed are leading the fashion in Chinese decoration field. We have more than 140 chain shops and own several patents in China. Our products sell well in Europe, the Middle East and North America.
Test Report
Fire test report
| Report No. | V03-1300143 | Specification | 200×10mm | ||||
| Product | PVC Wall Panel | Standard | BS EN 13501-1:2007 | ||||
| Test Items | Measure Unit |
Technical Requirement |
Test Results |
Individual Judgment |
|||
|
Fire growth rate index (Figra) |
W/s | C | ≤250 | 105 | Compliant | ||
|
Lateral flame spread ( LFS) |
m | <edge of specimen | Yes | Compliant | |||
|
Total heat release within 600 s(THR 600s) |
MJ | ≤15 | 11.5 | Compliant | |||
| Flame spread(Fs) | Surface | mm | ≤150 | 30 | Compliant | ||
| Edge | 33 | Compliant | |||||
|
Smoke growth rate (SMOGRA) |
m2/s2 | S2 | ≤180 | 192 |
S3 Compliant |
||
|
Total smoke production within 600 s(THR 600s) |
m2 | ≤200 | 666 | ||||
| Flaming droplests/particles | ------ | d0 |
No flaming droplets/particles occur within 600s |
Yes | Compliant | ||
| Ignition of the filter paper | ------ | No ignition of the filter paper | Yes | Compliant | |||
| Conclusion |
The combustion performance of sample is satisfied BS EN 13501-1:2007 about grade C-s3,d0. |
||||||
Antimicrobial Test Report
|
Item Name |
Escherichia coli ATCC 25922 | |
| After 24th Average of the viable cell(cfu/piece) | Antimicrobial rate (%) | |
| Control | 5.6×106 | ------ |
| Sample | <20 | >99 |
| Staphylococcus aureus ATCC6538 | ||
| Control | 4.2×105 | ------ |
| Sample | 1.1×103 | >99 |
